41mm High Torque Hybrid Step Motor Nema 17 0.35nm 280 oz stepper motor 57BYGHM021A

Brand Name : HeTai

Model Number : 57BYGHM021A

Certification : CE ROHS ISO

Place of Origin : China

MOQ : 50

Price : USD

Payment Terms : L/C, D/P, T/T, Western Union, MoneyGram

Supply Ability : 10000 PCS/MONTH

Delivery Time : 25 DAYS

Packaging Details : Carton with Inner Foam Box, Pallet

Product name : Hybrid stepping motor

Temperature Rise : 80 ℃ Max

Ambient Temperature : -20℃~+50℃

Step Accuracy : ± 5%

Dielectric Strength : 500VAC 1 minute

Insulation Resistance : 100MΩ Min.500VC DC

Max Radial Force : 75N (20mm from front flange)

Max Axial Force : 15N

Contact Now

57BYGHM021A CE ROHS ISO 41mm High Torque Hybrid Step Motor Nema 17 Customization

Construction & Working Principle

The construction of a stepper motor is fairly related to a DC motor. It includes a permanent magnet like Rotor which is in the middle & it will turn once force acts on it. This rotor is enclosed through a no. of the stator which is wound through a magnetic coil all over it. The stator is arranged near to rotor so that magnetic fields within the stators can control the movement of the rotor.

Electrical Specification:

Model Number
 57BYGHM021A
Step Accuracy
± 5%
Step Angle
0.9°
Lead Wire
 4
Voltage (V)
4
Current (A/Phase)
1.1
Holding Torque (N.m)
0.35
Resistance (Ω/phase) 1.4
Inductance (mH/phase) 2.0
Motor length (MM) 41
Motr Weight(K/g) 0.45
Insulation Class B


*Products can be customized by special request.

Wiring Diagram

41mm High Torque Hybrid Step Motor Nema 17 0.35nm 280 oz stepper motor 57BYGHM021A
Mechanical Dimension
41mm High Torque Hybrid Step Motor Nema 17 0.35nm 280 oz stepper motor 57BYGHM021A
Specification of Other Models:
MODEL STEP ANGLE
(°/STEP)		 LEAD WIRE
(NO.)		 VOLTAGE
(V)		 CURRENT
(A/PHASE)		 RESISTANCE
(Ω/PHASE)		 INDUCTANCE
(MH/PHASE)		 HOLDING TORQUE
(KG.CM)		 MOTOR HEIGHT
L(MM)		 MOTOR WEIGHT
(KG)
57BYGHM002-01 0.9 6 2.8 2.0 1.4 2.0 3.5 41 0.45
57BYGHM200-03A 0.9 4 3.4 1.0 3.4 12 7.0 51 0.56
57BYGHM203-04 0.9 6 12 0.38 32.0 38 5.5 51 0.56
57BYGHM401-09 0.9 6 7.4 1.0 7.4 17 9.0 56 0.70
57BYGHM414 0.9 4 1.7 4.2 0.4 1.0 11 56 0.70
57BYGHM604-17 0.9 4 3.2 2.8 1.13 6.4 15 78 1.00
57BYGHM601-05 0.9 6 8.6 1.0 8.6 20 13 78 1.00

*Products can be customized by special request.

*Can match with gearbox 42, 52, 56

Based on all this advantages, our company specializes in producing hybrid stepping motors, DC brushless motors, servo motors, gearbox motors and so on. The products are applied in robots, packing machinery, textile machinery, medical instruments, printing machinery, intelligent logistics equipment... Hetai also sends its products to USA, Europe, Southeast Asia and all-around China

41mm High Torque Hybrid Step Motor Nema 17 0.35nm 280 oz stepper motor 57BYGHM021A

41mm High Torque Hybrid Step Motor Nema 17 0.35nm 280 oz stepper motor 57BYGHM021A
